C110 White/Semi-Specular

C110 White/Semi-Specular

C110 White/Specular

C110 White/Specular

C110 White/White

C110 White/White

C110 Black/Semi-Specular

C110 Black/Semi-Specular

C110 Black/Specular

C110 Black/Specular

C110 Black/Black

C110 Black/Black

Explore our product range

C110 White/Semi-Specular
C110 White/Specular
C110 White/White
C110 Black/Semi-Specular
C110 Black/Specular
C110 Black/Black

Overview

Featuring a range of lumen outputs, a choice of reflector finishes and medium and wide distribution patterns the Mirage 3 C110 series is as much at home in feature areas as it is in functional spaces.

Optics

  • Light outputs ranging from 289 lumens to 3179 lumens
  • Efficacies up to 123.5 ll/cw
  • Available in four reflector finishes:
     - Black
     - White
     - Semi-Specular
     - Specular
  • Available with colour temperature of 3000K and 4000K
  • Ra80 and Ra90 colour rendering as standard
  • Medium and wide beam distributions, ideal for creating both accent and ambient lighting

For specific product variant information, including lifetime, efficacy, power, output and electrical data, please click on the individual part number under 'Order Codes' and view the datasheet

Lifetime Data
Version L70B50 L80B50 L90B50
8.4W >100K >100K 65K
16.6W >100K >100K 65K
26.5W >100K >92K 42K



Emergency Outputs
Version Medium Beam Wide Beam
8.4W 41% 41%
16.6W 21% 21%
26.5W 12% 12%



Body

  • IP44 as standard
  • Precision injection moulded reflectors available in black, white, semi-specular and specular
  • Slim 11mm bezel finished in:
    • Black, closest RAL colour 9005
    • White, closest RAL colour 9003
  • Graphite embedded heatsink
  • Rapid installation guaranteed with simple spring assembly
  • Luminaire supplied complete with driver
  • Suitable for ceilings 1-50mm thick
  • Integral emergency options; 3hr and COMEPS
  • Also available with 'EW' Routefinder Wireless for addressable emergency testing without the need for a 2 core communication cable
  • Emergency variants supplied with Lithium Iron Phosphate (LiFePO4) battery technology; featuring extended design life reducing replacement frequency to lower total cost of ownership, and advancing sustainability through support for end of life recycling
  • Note: All DALI variants require 1 DALI address per driver. COMEPS variants will require an additional DALI address.

Customise your solution

Explore custom made

Create your own

Customise this product

Looking for a custom made solution?

Our Custom Made facility caters to your unique requirements, whether you need completely bespoke luminaires or adaptations to standard products. Please complete the form below and we will be in touch to discuss your unique requirements.


Click on part code below for downloads

Part Code Product Colour Colour Temperature Driver Type Emergency Type Distribution Length / Diameter (mm) Output (lm) Power (W) Nominal Lumens
M2MY24K8M1 SemiSpec Reflector,White Bezel 4000K, Ra80 DALI LED Driver N/A Medium 119 976 8.4 600 - 1100
M2MY34K8M1 SemiSpec Reflector,White Bezel 4000K, Ra80 DALI LED Driver N/A Medium 119 1743 16.6 1200 - 2100
M2MY44K8M1 SemiSpec Reflector,White Bezel 4000K, Ra80 DALI LED Driver N/A Medium 119 3084 26.5 2200 - 3100
M2WY24K8M1 SemiSpec Reflector,White Bezel 4000K, Ra80 DALI LED Driver N/A Wide 119 793 8.4 600 - 1100
M2WY34K8M1 SemiSpec Reflector,White Bezel 4000K, Ra80 DALI LED Driver N/A Wide 119 1551 16.6 1200 - 2100
M2WY44K8M1 SemiSpec Reflector,White Bezel 4000K, Ra80 DALI LED Driver N/A Wide 119 2332 26.5 2200 - 3100
M2MH24K8M1 SemiSpec Reflector,White Bezel 4000K, Ra80 Fixed Output N/A Medium 119 976 8.4 600 - 1100
M2MH34K8M1 SemiSpec Reflector,White Bezel 4000K, Ra80 Fixed Output N/A Medium 119 1743 16.6 1200 - 2100
M2MH44K8M1 SemiSpec Reflector,White Bezel 4000K, Ra80 Fixed Output N/A Medium 119 3084 26.5 2200 - 3100
M2WH24K8M1 SemiSpec Reflector,White Bezel 4000K, Ra80 Fixed Output N/A Wide 119 793 8.4 600 - 1100
M2WH34K8M1 SemiSpec Reflector,White Bezel 4000K, Ra80 Fixed Output N/A Wide 119 1551 16.6 1200 - 2100
M2WH44K8M1 SemiSpec Reflector,White Bezel 4000K, Ra80 Fixed Output N/A Wide 119 2332 26.5 2200 - 3100
M2MY23K8M1 SemiSpec Reflector,White Bezel 3000K, RA80 DALI LED Driver N/A Medium 119 907.68 8.4 600 - 1100
M2MY33K8M1 SemiSpec Reflector,White Bezel 3000K, RA80 DALI LED Driver N/A Medium 119 1620.99 16.6 1200 - 2100
M2MY43K8M1 SemiSpec Reflector,White Bezel 3000K, RA80 DALI LED Driver N/A Medium 119 2868.12 26.5 2200 - 3100
M2WY23K8M1 SemiSpec Reflector,White Bezel 3000K, RA80 DALI LED Driver N/A Wide 119 737.49 8.4 600 - 1100
M2WY33K8M1 SemiSpec Reflector,White Bezel 3000K, RA80 DALI LED Driver N/A Wide 119 1442.43 16.6 1200 - 2100
M2WY43K8M1 SemiSpec Reflector,White Bezel 3000K, RA80 DALI LED Driver N/A Wide 119 2168.76 26.5 1200 - 2100
M2MH23K8M1 SemiSpec Reflector,White Bezel 3000K, RA80 Fixed Output N/A Medium 119 907.68 8.4 600 - 1100
M2MH33K8M1 SemiSpec Reflector,White Bezel 3000K, RA80 Fixed Output N/A Medium 119 1620.99 16.6 1200 - 2100
M2MH43K8M1 SemiSpec Reflector,White Bezel 3000K, RA80 Fixed Output N/A Medium 119 2868.12 26.5 2200 - 3100
M2WH23K8M1 SemiSpec Reflector,White Bezel 3000K, RA80 Fixed Output N/A Wide 119 737.49 8.4 600 - 1100
M2WH33K8M1 SemiSpec Reflector,White Bezel 3000K, RA80 Fixed Output N/A Wide 119 1442.43 16.6 1200 - 2100
M2WH43K8M1 SemiSpec Reflector,White Bezel 3000K, RA80 Fixed Output N/A Wide 119 2168.76 26.5 1200 - 2100
M2MY24K9M1 SemiSpec Reflector,White Bezel 4000K, Ra90 DALI LED Driver N/A Medium 119 810.08 8.4 600 - 1100
M2MY34K9M1 SemiSpec Reflector,White Bezel 4000K, Ra90 DALI LED Driver N/A Medium 119 1446.69 16.6 1200 - 2100
M2MY44K9M1 SemiSpec Reflector,White Bezel 4000K, Ra90 DALI LED Driver N/A Medium 119 2559.72 26.5 2200 - 3100
M2WY24K9M1 SemiSpec Reflector,White Bezel 4000K, Ra90 DALI LED Driver N/A Wide 119 658.19 8.4 600 - 1100
M2WY34K9M1 SemiSpec Reflector,White Bezel 4000K, Ra90 DALI LED Driver N/A Wide 119 1287.33 16.6 1200 - 2100
M2WY44K9M1 SemiSpec Reflector,White Bezel 4000K, Ra90 DALI LED Driver N/A Wide 119 1935.56 26.5 1200 - 2100
M2MH24K9M1 SemiSpec Reflector,White Bezel 4000K, Ra90 Fixed Output N/A Medium 119 810.08 8.4 600 - 1100
M2MH34K9M1 SemiSpec Reflector,White Bezel 4000K, Ra90 Fixed Output N/A Medium 119 1446.69 16.6 1200 - 2100
M2MH44K9M1 SemiSpec Reflector,White Bezel 4000K, Ra90 Fixed Output N/A Medium 119 2559.72 26.5 2200 - 3100
M2WH24K9M1 SemiSpec Reflector,White Bezel 4000K, Ra90 Fixed Output N/A Wide 119 658.19 8.4 600 - 1100
M2WH34K9M1 SemiSpec Reflector,White Bezel 4000K, Ra90 Fixed Output N/A Wide 119 1287.33 16.6 1200 - 2100
M2WH44K9M1 SemiSpec Reflector,White Bezel 4000K, Ra90 Fixed Output N/A Wide 119 1935.56 26.5 1200 - 2100
M2MY23K9M1 SemiSpec Reflector,White Bezel 3000K, RA90 DALI LED Driver N/A Medium 119 751.52 8.4 600 - 1100
M2MY33K9M1 SemiSpec Reflector,White Bezel 3000K, RA90 DALI LED Driver N/A Medium 119 1342.11 16.6 1200 - 2100
M2MY43K9M1 SemiSpec Reflector,White Bezel 3000K, RA90 DALI LED Driver N/A Medium 119 2374.68 26.5 2200 - 3100
M2WY23K9M1 SemiSpec Reflector,White Bezel 3000K, RA90 DALI LED Driver N/A Wide 119 610.61 8.4 600 - 1100
M2WY33K9M1 SemiSpec Reflector,White Bezel 3000K, RA90 DALI LED Driver N/A Wide 119 1194.27 16.6 600 - 1100
M2WY43K9M1 SemiSpec Reflector,White Bezel 3000K, RA90 DALI LED Driver N/A Wide 119 1795.64 26.5 1200 - 2100
M2MH23K9M1 SemiSpec Reflector,White Bezel 3000K, RA90 Fixed Output N/A Medium 119 751.52 8.4 600 - 1100
M2MH33K9M1 SemiSpec Reflector,White Bezel 3000K, RA90 Fixed Output N/A Medium 119 1342.11 16.6 1200 - 2100
M2MH43K9M1 SemiSpec Reflector,White Bezel 3000K, RA90 Fixed Output N/A Medium 119 2374.68 26.5 2200 - 3100
M2WH23K9M1 SemiSpec Reflector,White Bezel 3000K, RA90 Fixed Output N/A Wide 119 610.61 8.4 600 - 1100
M2WH33K9M1 SemiSpec Reflector,White Bezel 3000K, RA90 Fixed Output N/A Wide 119 1194.27 16.6 600 - 1100
M2WH43K9M1 SemiSpec Reflector,White Bezel 3000K, RA90 Fixed Output N/A Wide 119 1795.64 26.5 1200 - 2100
M2MY24K8M2 SemiSpec Reflector,Black Bezel 4000K, Ra80 DALI LED Driver N/A Medium 119 976 8.4 600 - 1100
M2MY34K8M2 SemiSpec Reflector,Black Bezel 4000K, Ra80 DALI LED Driver N/A Medium 119 1743 16.6 1200 - 2100
M2MY44K8M2 SemiSpec Reflector,Black Bezel 4000K, Ra80 DALI LED Driver N/A Medium 119 3084 26.5 2200 - 3100
M2WY24K8M2 SemiSpec Reflector,Black Bezel 4000K, Ra80 DALI LED Driver N/A Wide 119 793 8.4 600 - 1100
M2WY34K8M2 SemiSpec Reflector,Black Bezel 4000K, Ra80 DALI LED Driver N/A Wide 119 1551 16.6 1200 - 2100
M2WY44K8M2 SemiSpec Reflector,Black Bezel 4000K, Ra80 DALI LED Driver N/A Wide 119 2332 26.5 2200 - 3100
M2MH24K8M2 SemiSpec Reflector,Black Bezel 4000K, Ra80 Fixed Output N/A Medium 119 976 8.4 600 - 1100
M2MH34K8M2 SemiSpec Reflector,Black Bezel 4000K, Ra80 Fixed Output N/A Medium 119 1743 16.6 1200 - 2100
M2MH44K8M2 SemiSpec Reflector,Black Bezel 4000K, Ra80 Fixed Output N/A Medium 119 3084 26.5 2200 - 3100
M2WH24K8M2 SemiSpec Reflector,Black Bezel 4000K, Ra80 Fixed Output N/A Wide 119 793 8.4 600 - 1100
M2WH34K8M2 SemiSpec Reflector,Black Bezel 4000K, Ra80 Fixed Output N/A Wide 119 1551 16.6 1200 - 2100
M2WH44K8M2 SemiSpec Reflector,Black Bezel 4000K, Ra80 Fixed Output N/A Wide 119 2332 26.5 2200 - 3100
M2MY23K8M2 SemiSpec Reflector,Black Bezel 3000K, RA80 DALI LED Driver N/A Medium 119 907.68 8.4 600 - 1100
M2MY33K8M2 SemiSpec Reflector,Black Bezel 3000K, RA80 DALI LED Driver N/A Medium 119 1620.99 16.6 1200 - 2100
M2MY43K8M2 SemiSpec Reflector,Black Bezel 3000K, RA80 DALI LED Driver N/A Medium 119 2868.12 26.5 2200 - 3100
M2WY23K8M2 SemiSpec Reflector,Black Bezel 3000K, RA80 DALI LED Driver N/A Wide 119 737.49 8.4 600 - 1100
M2WY33K8M2 SemiSpec Reflector,Black Bezel 3000K, RA80 DALI LED Driver N/A Wide 119 1442.43 16.6 1200 - 2100
M2WY43K8M2 SemiSpec Reflector,Black Bezel 3000K, RA80 DALI LED Driver N/A Wide 119 2168.76 26.5 1200 - 2100
M2MH23K8M2 SemiSpec Reflector,Black Bezel 3000K, RA80 Fixed Output N/A Medium 119 907.68 8.4 600 - 1100
M2MH33K8M2 SemiSpec Reflector,Black Bezel 3000K, RA80 Fixed Output N/A Medium 119 1620.99 16.6 1200 - 2100
M2MH43K8M2 SemiSpec Reflector,Black Bezel 3000K, RA80 Fixed Output N/A Medium 119 2868.12 26.5 2200 - 3100
M2WH23K8M2 SemiSpec Reflector,Black Bezel 3000K, RA80 Fixed Output N/A Wide 119 737.49 8.4 600 - 1100
M2WH33K8M2 SemiSpec Reflector,Black Bezel 3000K, RA80 Fixed Output N/A Wide 119 1442.43 16.6 1200 - 2100
M2WH43K8M2 SemiSpec Reflector,Black Bezel 3000K, RA80 Fixed Output N/A Wide 119 2168.76 26.5 1200 - 2100
M2MY24K9M2 SemiSpec Reflector,Black Bezel 4000K, Ra90 DALI LED Driver N/A Medium 119 810.08 8.4 600 - 1100
M2MY34K9M2 SemiSpec Reflector,Black Bezel 4000K, Ra90 DALI LED Driver N/A Medium 119 1446.69 16.6 1200 - 2100
M2MY44K9M2 SemiSpec Reflector,Black Bezel 4000K, Ra90 DALI LED Driver N/A Medium 119 2559.72 26.5 2200 - 3100
M2WY24K9M2 SemiSpec Reflector,Black Bezel 4000K, Ra90 DALI LED Driver N/A Wide 119 658.19 8.4 600 - 1100
M2WY34K9M2 SemiSpec Reflector,Black Bezel 4000K, Ra90 DALI LED Driver N/A Wide 119 1287.33 16.6 1200 - 2100
M2WY44K9M2 SemiSpec Reflector,Black Bezel 4000K, Ra90 DALI LED Driver N/A Wide 119 1935.56 26.5 1200 - 2100
M2MH24K9M2 SemiSpec Reflector,Black Bezel 4000K, Ra90 Fixed Output N/A Medium 119 810.08 8.4 600 - 1100
M2MH34K9M2 SemiSpec Reflector,Black Bezel 4000K, Ra90 Fixed Output N/A Medium 119 1446.69 16.6 1200 - 2100
M2MH44K9M2 SemiSpec Reflector,Black Bezel 4000K, Ra90 Fixed Output N/A Medium 119 2559.72 26.5 2200 - 3100
M2WH24K9M2 SemiSpec Reflector,Black Bezel 4000K, Ra90 Fixed Output N/A Wide 119 658.19 8.4 600 - 1100
M2WH34K9M2 SemiSpec Reflector,Black Bezel 4000K, Ra90 Fixed Output N/A Wide 119 1287.33 16.6 1200 - 2100
M2WH44K9M2 SemiSpec Reflector,Black Bezel 4000K, Ra90 Fixed Output N/A Wide 119 1935.56 26.5 1200 - 2100
M2MY23K9M2 SemiSpec Reflector,Black Bezel 3000K, RA90 DALI LED Driver N/A Medium 119 751.52 8.4 600 - 1100
M2MY33K9M2 SemiSpec Reflector,Black Bezel 3000K, RA90 DALI LED Driver N/A Medium 119 1342.11 16.6 1200 - 2100
M2MY43K9M2 SemiSpec Reflector,Black Bezel 3000K, RA90 DALI LED Driver N/A Medium 119 2374.68 26.5 2200 - 3100
M2WY23K9M2 SemiSpec Reflector,Black Bezel 3000K, RA90 DALI LED Driver N/A Wide 119 610.61 8.4 600 - 1100
M2WY33K9M2 SemiSpec Reflector,Black Bezel 3000K, RA90 DALI LED Driver N/A Wide 119 1194.27 16.6 600 - 1100
M2WY43K9M2 SemiSpec Reflector,Black Bezel 3000K, RA90 DALI LED Driver N/A Wide 119 1795.64 26.5 1200 - 2100
M2MH23K9M2 SemiSpec Reflector,Black Bezel 3000K, RA90 Fixed Output N/A Medium 119 751.52 8.4 600 - 1100
M2MH33K9M2 SemiSpec Reflector,Black Bezel 3000K, RA90 Fixed Output N/A Medium 119 1342.11 16.6 1200 - 2100
M2MH43K9M2 SemiSpec Reflector,Black Bezel 3000K, RA90 Fixed Output N/A Medium 119 2374.68 26.5 2200 - 3100
M2WH23K9M2 SemiSpec Reflector,Black Bezel 3000K, RA90 Fixed Output N/A Wide 119 610.61 8.4 600 - 1100
M2WH33K9M2 SemiSpec Reflector,Black Bezel 3000K, RA90 Fixed Output N/A Wide 119 1194.27 16.6 600 - 1100
M2WH43K9M2 SemiSpec Reflector,Black Bezel 3000K, RA90 Fixed Output N/A Wide 119 1795.64 26.5 1200 - 2100
M2MY24K8M1LEM SemiSpec Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 976 8.4 600 - 1100
M2MY24K8M1LEP SemiSpec Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 976 8.4 600 - 1100
M2MY34K8M1LEM SemiSpec Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 1743 16.6 1200 - 2100
M2MY34K8M1LEP SemiSpec Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 1743 16.6 1200 - 2100
M2MY44K8M1LEM SemiSpec Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 3084 26.5 2200 - 3100
M2MY44K8M1LEP SemiSpec Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 3084 26.5 2200 - 3100
M2WY24K8M1LEM SemiSpec Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 793 8.4 600 - 1100
M2WY24K8M1LEP SemiSpec Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 793 8.4 600 - 1100
M2WY34K8M1LEM SemiSpec Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 1551 16.6 1200 - 2100
M2WY34K8M1LEP SemiSpec Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 1551 16.6 1200 - 2100
M2WY44K8M1LEM SemiSpec Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 2332 26.5 2200 - 3100
M2WY44K8M1LEP SemiSpec Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 2332 26.5 2200 - 3100
M2MH24K8M1LEM SemiSpec Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 976 8.4 600 - 1100
M2MH24K8M1LEP SemiSpec Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 976 8.4 600 - 1100
M2MH34K8M1LEM SemiSpec Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 1743 16.6 1200 - 2100
M2MH34K8M1LEP SemiSpec Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 1743 16.6 1200 - 2100
M2MH44K8M1LEM SemiSpec Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 3084 26.5 2200 - 3100
M2MH44K8M1LEP SemiSpec Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 3084 26.5 2200 - 3100
M2WH24K8M1LEM SemiSpec Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 793 8.4 600 - 1100
M2WH24K8M1LEP SemiSpec Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 793 8.4 600 - 1100
M2WH34K8M1LEM SemiSpec Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 1551 16.6 1200 - 2100
M2WH34K8M1LEP SemiSpec Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 1551 16.6 1200 - 2100
M2WH44K8M1LEM SemiSpec Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 2332 26.5 2200 - 3100
M2WH44K8M1LEP SemiSpec Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 2332 26.5 2200 - 3100
M2MY23K8M1LEM SemiSpec Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 907.68 8.4 600 - 1100
M2MY23K8M1LEP SemiSpec Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 907.68 8.4 600 - 1100
M2MY33K8M1LEM SemiSpec Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 1620.99 16.6 1200 - 2100
M2MY33K8M1LEP SemiSpec Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 1620.99 16.6 1200 - 2100
M2MY43K8M1LEM SemiSpec Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 2868.12 26.5 2200 - 3100
M2MY43K8M1LEP SemiSpec Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 2868.12 26.5 2200 - 3100
M2WY23K8M1LEM SemiSpec Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 737.49 8.4 600 - 1100
M2WY23K8M1LEP SemiSpec Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 737.49 8.4 600 - 1100
M2WY33K8M1LEM SemiSpec Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 1442.43 16.6 1200 - 2100
M2WY33K8M1LEP SemiSpec Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 1442.43 16.6 1200 - 2100
M2WY43K8M1LEM SemiSpec Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 2168.76 26.5 1200 - 2100
M2WY43K8M1LEP SemiSpec Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 2168.76 26.5 1200 - 2100
M2MH23K8M1LEM SemiSpec Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 907.68 8.4 600 - 1100
M2MH23K8M1LEP SemiSpec Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 907.68 8.4 600 - 1100
M2MH33K8M1LEM SemiSpec Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 1620.99 16.6 1200 - 2100
M2MH33K8M1LEP SemiSpec Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 1620.99 16.6 1200 - 2100
M2MH43K8M1LEM SemiSpec Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 2868.12 26.5 2200 - 3100
M2MH43K8M1LEP SemiSpec Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 2868.12 26.5 2200 - 3100
M2WH23K8M1LEM SemiSpec Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 737.49 8.4 600 - 1100
M2WH23K8M1LEP SemiSpec Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 737.49 8.4 600 - 1100
M2WH33K8M1LEM SemiSpec Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 1442.43 16.6 1200 - 2100
M2WH33K8M1LEP SemiSpec Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 1442.43 16.6 1200 - 2100
M2WH43K8M1LEM SemiSpec Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 2168.76 26.5 1200 - 2100
M2WH43K8M1LEP SemiSpec Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 2168.76 26.5 1200 - 2100
M2MY24K9M1LEM SemiSpec Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 810.08 8.4 600 - 1100
M2MY24K9M1LEP SemiSpec Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 810.08 8.4 600 - 1100
M2MY34K9M1LEM SemiSpec Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 1446.69 16.6 1200 - 2100
M2MY34K9M1LEP SemiSpec Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 1446.69 16.6 1200 - 2100
M2MY44K9M1LEM SemiSpec Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 2559.72 26.5 2200 - 3100
M2MY44K9M1LEP SemiSpec Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 2559.72 26.5 2200 - 3100
M2WY24K9M1LEM SemiSpec Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 658.19 8.4 600 - 1100
M2WY24K9M1LEP SemiSpec Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 658.19 8.4 600 - 1100
M2WY34K9M1LEM SemiSpec Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 1287.33 16.6 1200 - 2100
M2WY34K9M1LEP SemiSpec Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 1287.33 16.6 1200 - 2100
M2WY44K9M1LEM SemiSpec Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 1935.56 26.5 1200 - 2100
M2WY44K9M1LEP SemiSpec Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 1935.56 26.5 1200 - 2100
M2MH24K9M1LEM SemiSpec Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 810.08 8.4 600 - 1100
M2MH24K9M1LEP SemiSpec Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 810.08 8.4 600 - 1100
M2MH34K9M1LEM SemiSpec Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 1446.69 16.6 1200 - 2100
M2MH34K9M1LEP SemiSpec Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 1446.69 16.6 1200 - 2100
M2MH44K9M1LEM SemiSpec Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 2559.72 26.5 2200 - 3100
M2MH44K9M1LEP SemiSpec Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 2559.72 26.5 2200 - 3100
M2WH24K9M1LEM SemiSpec Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 658.19 8.4 600 - 1100
M2WH24K9M1LEP SemiSpec Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 658.19 8.4 600 - 1100
M2WH34K9M1LEM SemiSpec Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 1287.33 16.6 1200 - 2100
M2WH34K9M1LEP SemiSpec Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 1287.33 16.6 1200 - 2100
M2WH44K9M1LEM SemiSpec Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 1935.56 26.5 1200 - 2100
M2WH44K9M1LEP SemiSpec Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 1935.56 26.5 1200 - 2100
M2MY23K9M1LEM SemiSpec Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 751.52 8.4 600 - 1100
M2MY23K9M1LEP SemiSpec Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 751.52 8.4 600 - 1100
M2MY33K9M1LEM SemiSpec Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 1342.11 16.6 1200 - 2100
M2MY33K9M1LEP SemiSpec Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 1342.11 16.6 1200 - 2100
M2MY43K9M1LEM SemiSpec Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 2374.68 26.5 2200 - 3100
M2MY43K9M1LEP SemiSpec Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 2374.68 26.5 2200 - 3100
M2WY23K9M1LEM SemiSpec Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 610.61 8.4 600 - 1100
M2WY23K9M1LEP SemiSpec Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 610.61 8.4 600 - 1100
M2WY33K9M1LEM SemiSpec Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 1194.27 16.6 600 - 1100
M2WY33K9M1LEP SemiSpec Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 1194.27 16.6 600 - 1100
M2WY43K9M1LEM SemiSpec Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 1795.64 26.5 1200 - 2100
M2WY43K9M1LEP SemiSpec Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 1795.64 26.5 1200 - 2100
M2MH23K9M1LEM SemiSpec Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 751.52 8.4 600 - 1100
M2MH23K9M1LEP SemiSpec Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 751.52 8.4 600 - 1100
M2MH33K9M1LEM SemiSpec Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 1342.11 16.6 1200 - 2100
M2MH33K9M1LEP SemiSpec Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 1342.11 16.6 1200 - 2100
M2MH43K9M1LEM SemiSpec Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 2374.68 26.5 2200 - 3100
M2MH43K9M1LEP SemiSpec Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 2374.68 26.5 2200 - 3100
M2WH23K9M1LEM SemiSpec Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 610.61 8.4 600 - 1100
M2WH23K9M1LEP SemiSpec Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 610.61 8.4 600 - 1100
M2WH33K9M1LEM SemiSpec Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 1194.27 16.6 600 - 1100
M2WH33K9M1LEP SemiSpec Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 1194.27 16.6 600 - 1100
M2WH43K9M1LEM SemiSpec Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 1795.64 26.5 1200 - 2100
M2WH43K9M1LEP SemiSpec Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 1795.64 26.5 1200 - 2100
M2MY24K8M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 976 8.4 600 - 1100
M2MY24K8M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 976 8.4 600 - 1100
M2MY34K8M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 1743 16.6 1200 - 2100
M2MY34K8M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 1743 16.6 1200 - 2100
M2MY44K8M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 3084 26.5 2200 - 3100
M2MY44K8M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 3084 26.5 2200 - 3100
M2WY24K8M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 793 8.4 600 - 1100
M2WY24K8M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 793 8.4 600 - 1100
M2WY34K8M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 1551 16.6 1200 - 2100
M2WY34K8M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 1551 16.6 1200 - 2100
M2WY44K8M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 2332 26.5 2200 - 3100
M2WY44K8M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 2332 26.5 2200 - 3100
M2MH24K8M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 976 8.4 600 - 1100
M2MH24K8M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 976 8.4 600 - 1100
M2MH34K8M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 1743 16.6 1200 - 2100
M2MH34K8M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 1743 16.6 1200 - 2100
M2MH44K8M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 3084 26.5 2200 - 3100
M2MH44K8M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 3084 26.5 2200 - 3100
M2WH24K8M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 793 8.4 600 - 1100
M2WH24K8M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 793 8.4 600 - 1100
M2WH34K8M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 1551 16.6 1200 - 2100
M2WH34K8M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 1551 16.6 1200 - 2100
M2WH44K8M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 2332 26.5 2200 - 3100
M2WH44K8M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 2332 26.5 2200 - 3100
M2MY23K8M2LEM SemiSpec Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 907.68 8.4 600 - 1100
M2MY23K8M2LEP SemiSpec Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 907.68 8.4 600 - 1100
M2MY33K8M2LEM SemiSpec Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 1620.99 16.6 1200 - 2100
M2MY33K8M2LEP SemiSpec Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 1620.99 16.6 1200 - 2100
M2MY43K8M2LEM SemiSpec Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 2868.12 26.5 2200 - 3100
M2MY43K8M2LEP SemiSpec Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 2868.12 26.5 2200 - 3100
M2WY23K8M2LEM SemiSpec Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 737.49 8.4 600 - 1100
M2WY23K8M2LEP SemiSpec Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 737.49 8.4 600 - 1100
M2WY33K8M2LEM SemiSpec Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 1442.43 16.6 1200 - 2100
M2WY33K8M2LEP SemiSpec Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 1442.43 16.6 1200 - 2100
M2WY43K8M2LEM SemiSpec Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 2168.76 26.5 1200 - 2100
M2WY43K8M2LEP SemiSpec Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 2168.76 26.5 1200 - 2100
M2MH23K8M2LEM SemiSpec Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 907.68 8.4 600 - 1100
M2MH23K8M2LEP SemiSpec Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 907.68 8.4 600 - 1100
M2MH33K8M2LEM SemiSpec Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 1620.99 16.6 1200 - 2100
M2MH33K8M2LEP SemiSpec Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 1620.99 16.6 1200 - 2100
M2MH43K8M2LEM SemiSpec Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 2868.12 26.5 2200 - 3100
M2MH43K8M2LEP SemiSpec Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 2868.12 26.5 2200 - 3100
M2WH23K8M2LEM SemiSpec Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 737.49 8.4 600 - 1100
M2WH23K8M2LEP SemiSpec Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 737.49 8.4 600 - 1100
M2WH33K8M2LEM SemiSpec Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 1442.43 16.6 1200 - 2100
M2WH33K8M2LEP SemiSpec Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 1442.43 16.6 1200 - 2100
M2WH43K8M2LEM SemiSpec Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 2168.76 26.5 1200 - 2100
M2WH43K8M2LEP SemiSpec Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 2168.76 26.5 1200 - 2100
M2MY24K9M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 810.08 8.4 600 - 1100
M2MY24K9M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 810.08 8.4 600 - 1100
M2MY34K9M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 1446.69 16.6 1200 - 2100
M2MY34K9M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 1446.69 16.6 1200 - 2100
M2MY44K9M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 2559.72 26.5 2200 - 3100
M2MY44K9M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 2559.72 26.5 2200 - 3100
M2WY24K9M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 658.19 8.4 600 - 1100
M2WY24K9M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 658.19 8.4 600 - 1100
M2WY34K9M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 1287.33 16.6 1200 - 2100
M2WY34K9M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 1287.33 16.6 1200 - 2100
M2WY44K9M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 1935.56 26.5 1200 - 2100
M2WY44K9M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 1935.56 26.5 1200 - 2100
M2MH24K9M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 810.08 8.4 600 - 1100
M2MH24K9M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 810.08 8.4 600 - 1100
M2MH34K9M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 1446.69 16.6 1200 - 2100
M2MH34K9M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 1446.69 16.6 1200 - 2100
M2MH44K9M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 2559.72 26.5 2200 - 3100
M2MH44K9M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 2559.72 26.5 2200 - 3100
M2WH24K9M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 658.19 8.4 600 - 1100
M2WH24K9M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 658.19 8.4 600 - 1100
M2WH34K9M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 1287.33 16.6 1200 - 2100
M2WH34K9M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 1287.33 16.6 1200 - 2100
M2WH44K9M2LEM SemiSpec Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 1935.56 26.5 1200 - 2100
M2WH44K9M2LEP SemiSpec Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 1935.56 26.5 1200 - 2100
M2MY23K9M2LEM SemiSpec Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 751.52 8.4 600 - 1100
M2MY23K9M2LEP SemiSpec Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 751.52 8.4 600 - 1100
M2MY33K9M2LEM SemiSpec Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 1342.11 16.6 1200 - 2100
M2MY33K9M2LEP SemiSpec Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 1342.11 16.6 1200 - 2100
M2MY43K9M2LEM SemiSpec Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 2374.68 26.5 2200 - 3100
M2MY43K9M2LEP SemiSpec Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 2374.68 26.5 2200 - 3100
M2WY23K9M2LEM SemiSpec Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 610.61 8.4 600 - 1100
M2WY23K9M2LEP SemiSpec Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 610.61 8.4 600 - 1100
M2WY33K9M2LEM SemiSpec Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 1194.27 16.6 600 - 1100
M2WY33K9M2LEP SemiSpec Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 1194.27 16.6 600 - 1100
M2WY43K9M2LEM SemiSpec Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 1795.64 26.5 1200 - 2100
M2WY43K9M2LEP SemiSpec Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 1795.64 26.5 1200 - 2100
M2MH23K9M2LEM SemiSpec Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 751.52 8.4 600 - 1100
M2MH23K9M2LEP SemiSpec Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 751.52 8.4 600 - 1100
M2MH33K9M2LEM SemiSpec Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 1342.11 16.6 1200 - 2100
M2MH33K9M2LEP SemiSpec Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 1342.11 16.6 1200 - 2100
M2MH43K9M2LEM SemiSpec Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 2374.68 26.5 2200 - 3100
M2MH43K9M2LEP SemiSpec Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 2374.68 26.5 2200 - 3100
M2WH23K9M2LEM SemiSpec Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 610.61 8.4 600 - 1100
M2WH23K9M2LEP SemiSpec Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 610.61 8.4 600 - 1100
M2WH33K9M2LEM SemiSpec Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 1194.27 16.6 600 - 1100
M2WH33K9M2LEP SemiSpec Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 1194.27 16.6 600 - 1100
M2WH43K9M2LEM SemiSpec Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 1795.64 26.5 1200 - 2100
M2WH43K9M2LEP SemiSpec Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 1795.64 26.5 1200 - 2100

Click on part code below for downloads

Part Code Product Colour Colour Temperature Driver Type Emergency Type Distribution Length / Diameter (mm) Output (lm) Power (W) Nominal Lumens
M2MY24K8W1 White Reflector,White Bezel 4000K, Ra80 DALI LED Driver N/A Medium 119 1034 8.4 600 - 1100
M2MY34K8W1 White Reflector,White Bezel 4000K, Ra80 DALI LED Driver N/A Medium 119 2050 16.6 1200 - 2100
M2MY44K8W1 White Reflector,White Bezel 4000K, Ra80 DALI LED Driver N/A Medium 119 3179 26.5 2200 - 3100
M2WY24K8W1 White Reflector,White Bezel 4000K, Ra80 DALI LED Driver N/A Wide 119 854 8.4 600 - 1100
M2WY34K8W1 White Reflector,White Bezel 4000K, Ra80 DALI LED Driver N/A Wide 119 1693 16.6 1200 - 2100
M2WY44K8W1 White Reflector,White Bezel 4000K, Ra80 DALI LED Driver N/A Wide 119 2501 26.5 2200 - 3100
M2MH24K8W1 White Reflector,White Bezel 4000K, Ra80 Fixed Output N/A Medium 119 1034 8.4 600 - 1100
M2MH34K8W1 White Reflector,White Bezel 4000K, Ra80 Fixed Output N/A Medium 119 2050 16.6 1200 - 2100
M2MH44K8W1 White Reflector,White Bezel 4000K, Ra80 Fixed Output N/A Medium 119 3179 26.5 2200 - 3100
M2WH24K8W1 White Reflector,White Bezel 4000K, Ra80 Fixed Output N/A Wide 119 854 8.4 600 - 1100
M2WH34K8W1 White Reflector,White Bezel 4000K, Ra80 Fixed Output N/A Wide 119 1693 16.6 1200 - 2100
M2WH44K8W1 White Reflector,White Bezel 4000K, Ra80 Fixed Output N/A Wide 119 2501 26.5 2200 - 3100
M2MY23K8W1 White Reflector,White Bezel 3000K, RA80 DALI LED Driver N/A Medium 119 961.62 8.4 600 - 1100
M2MY33K8W1 White Reflector,White Bezel 3000K, RA80 DALI LED Driver N/A Medium 119 1906.5 16.6 1200 - 2100
M2MY43K8W1 White Reflector,White Bezel 3000K, RA80 DALI LED Driver N/A Medium 119 2956.47 26.5 2200 - 3100
M2WY23K8W1 White Reflector,White Bezel 3000K, RA80 DALI LED Driver N/A Wide 119 794.22 8.4 600 - 1100
M2WY33K8W1 White Reflector,White Bezel 3000K, RA80 DALI LED Driver N/A Wide 119 1574.49 16.6 1200 - 2100
M2WY43K8W1 White Reflector,White Bezel 3000K, RA80 DALI LED Driver N/A Wide 119 2325.93 26.5 2200 - 3100
M2MH23K8W1 White Reflector,White Bezel 3000K, RA80 Fixed Output N/A Medium 119 961.62 8.4 600 - 1100
M2MH33K8W1 White Reflector,White Bezel 3000K, RA80 Fixed Output N/A Medium 119 1906.5 16.6 1200 - 2100
M2MH43K8W1 White Reflector,White Bezel 3000K, RA80 Fixed Output N/A Medium 119 2956.47 26.5 2200 - 3100
M2WH23K8W1 White Reflector,White Bezel 3000K, RA80 Fixed Output N/A Wide 119 794.22 8.4 600 - 1100
M2WH33K8W1 White Reflector,White Bezel 3000K, RA80 Fixed Output N/A Wide 119 1574.49 16.6 1200 - 2100
M2WH43K8W1 White Reflector,White Bezel 3000K, RA80 Fixed Output N/A Wide 119 2325.93 26.5 2200 - 3100
M2MY24K9W1 White Reflector,White Bezel 4000K, Ra90 DALI LED Driver N/A Medium 119 858.22 8.4 600 - 1100
M2MY34K9W1 White Reflector,White Bezel 4000K, Ra90 DALI LED Driver N/A Medium 119 1701.5 16.6 1200 - 2100
M2MY44K9W1 White Reflector,White Bezel 4000K, Ra90 DALI LED Driver N/A Medium 119 2638.57 26.5 2200 - 3100
M2WY24K9W1 White Reflector,White Bezel 4000K, Ra90 DALI LED Driver N/A Wide 119 708.82 8.4 600 - 1100
M2WY34K9W1 White Reflector,White Bezel 4000K, Ra90 DALI LED Driver N/A Wide 119 1405.19 16.6 1200 - 2100
M2WY44K9W1 White Reflector,White Bezel 4000K, Ra90 DALI LED Driver N/A Wide 119 2075.83 26.5 1200 - 2100
M2MH24K9W1 White Reflector,White Bezel 4000K, Ra90 Fixed Output N/A Medium 119 858.22 8.4 600 - 1100
M2MH34K9W1 White Reflector,White Bezel 4000K, Ra90 Fixed Output N/A Medium 119 1701.5 16.6 1200 - 2100
M2MH44K9W1 White Reflector,White Bezel 4000K, Ra90 Fixed Output N/A Medium 119 2638.57 26.5 2200 - 3100
M2WH24K9W1 White Reflector,White Bezel 4000K, Ra90 Fixed Output N/A Wide 119 708.82 8.4 600 - 1100
M2WH34K9W1 White Reflector,White Bezel 4000K, Ra90 Fixed Output N/A Wide 119 1405.19 16.6 1200 - 2100
M2WH44K9W1 White Reflector,White Bezel 4000K, Ra90 Fixed Output N/A Wide 119 2075.83 26.5 1200 - 2100
M2MY23K9W1 White Reflector,White Bezel 3000K, RA90 DALI LED Driver N/A Medium 119 796.18 8.4 600 - 1100
M2MY33K9W1 White Reflector,White Bezel 3000K, RA90 DALI LED Driver N/A Medium 119 1578.5 16.6 1200 - 2100
M2MY43K9W1 White Reflector,White Bezel 3000K, RA90 DALI LED Driver N/A Medium 119 2447.83 26.5 2200 - 3100
M2WY23K9W1 White Reflector,White Bezel 3000K, RA90 DALI LED Driver N/A Wide 119 657.58 8.4 600 - 1100
M2WY33K9W1 White Reflector,White Bezel 3000K, RA90 DALI LED Driver N/A Wide 119 1303.61 16.6 1200 - 2100
M2WY43K9W1 White Reflector,White Bezel 3000K, RA90 DALI LED Driver N/A Wide 119 1925.77 26.5 1200 - 2100
M2MH23K9W1 White Reflector,White Bezel 3000K, RA90 Fixed Output N/A Medium 119 796.18 8.4 600 - 1100
M2MH33K9W1 White Reflector,White Bezel 3000K, RA90 Fixed Output N/A Medium 119 1578.5 16.6 1200 - 2100
M2MH43K9W1 White Reflector,White Bezel 3000K, RA90 Fixed Output N/A Medium 119 2447.83 26.5 2200 - 3100
M2WH23K9W1 White Reflector,White Bezel 3000K, RA90 Fixed Output N/A Wide 119 657.58 8.4 600 - 1100
M2WH33K9W1 White Reflector,White Bezel 3000K, RA90 Fixed Output N/A Wide 119 1303.61 16.6 1200 - 2100
M2WH43K9W1 White Reflector,White Bezel 3000K, RA90 Fixed Output N/A Wide 119 1925.77 26.5 1200 - 2100
M2MY24K8W1LEM White Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 1034 8.4 600 - 1100
M2MY24K8W1LEP White Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 1034 8.4 600 - 1100
M2MY34K8W1LEM White Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 2050 16.6 1200 - 2100
M2MY34K8W1LEP White Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 2050 16.6 1200 - 2100
M2MY44K8W1LEM White Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 3179 26.5 2200 - 3100
M2MY44K8W1LEP White Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 3179 26.5 2200 - 3100
M2WY24K8W1LEM White Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 854 8.4 600 - 1100
M2WY24K8W1LEP White Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 854 8.4 600 - 1100
M2WY34K8W1LEM White Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 1693 16.6 1200 - 2100
M2WY34K8W1LEP White Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 1693 16.6 1200 - 2100
M2WY44K8W1LEM White Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 2501 26.5 2200 - 3100
M2WY44K8W1LEP White Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 2501 26.5 2200 - 3100
M2MH24K8W1LEM White Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 1034 8.4 600 - 1100
M2MH24K8W1LEP White Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 1034 8.4 600 - 1100
M2MH34K8W1LEM White Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 2050 16.6 1200 - 2100
M2MH34K8W1LEP White Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 2050 16.6 1200 - 2100
M2MH44K8W1LEM White Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 3179 26.5 2200 - 3100
M2MH44K8W1LEP White Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 3179 26.5 2200 - 3100
M2WH24K8W1LEM White Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 854 8.4 600 - 1100
M2WH24K8W1LEP White Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 854 8.4 600 - 1100
M2WH34K8W1LEM White Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 1693 16.6 1200 - 2100
M2WH34K8W1LEP White Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 1693 16.6 1200 - 2100
M2WH44K8W1LEM White Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 2501 26.5 2200 - 3100
M2WH44K8W1LEP White Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 2501 26.5 2200 - 3100
M2MY23K8W1LEM White Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 961.62 8.4 600 - 1100
M2MY23K8W1LEP White Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 961.62 8.4 600 - 1100
M2MY33K8W1LEM White Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 1906.5 16.6 1200 - 2100
M2MY33K8W1LEP White Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 1906.5 16.6 1200 - 2100
M2MY43K8W1LEM White Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 2956.47 26.5 2200 - 3100
M2MY43K8W1LEP White Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 2956.47 26.5 2200 - 3100
M2WY23K8W1LEM White Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 794.22 8.4 600 - 1100
M2WY23K8W1LEP White Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 794.22 8.4 600 - 1100
M2WY33K8W1LEM White Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 1574.49 16.6 1200 - 2100
M2WY33K8W1LEP White Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 1574.49 16.6 1200 - 2100
M2WY43K8W1LEM White Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 2325.93 26.5 2200 - 3100
M2WY43K8W1LEP White Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 2325.93 26.5 2200 - 3100
M2MH23K8W1LEM White Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 961.62 8.4 600 - 1100
M2MH23K8W1LEP White Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 961.62 8.4 600 - 1100
M2MH33K8W1LEM White Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 1906.5 16.6 1200 - 2100
M2MH33K8W1LEP White Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 1906.5 16.6 1200 - 2100
M2MH43K8W1LEM White Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 2956.47 26.5 2200 - 3100
M2MH43K8W1LEP White Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 2956.47 26.5 2200 - 3100
M2WH23K8W1LEM White Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 794.22 8.4 600 - 1100
M2WH23K8W1LEP White Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 794.22 8.4 600 - 1100
M2WH33K8W1LEM White Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 1574.49 16.6 1200 - 2100
M2WH33K8W1LEP White Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 1574.49 16.6 1200 - 2100
M2WH43K8W1LEM White Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 2325.93 26.5 2200 - 3100
M2WH43K8W1LEP White Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 2325.93 26.5 2200 - 3100
M2MY24K9W1LEM White Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 858.22 8.4 600 - 1100
M2MY24K9W1LEP White Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 858.22 8.4 600 - 1100
M2MY34K9W1LEM White Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 1701.5 16.6 1200 - 2100
M2MY34K9W1LEP White Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 1701.5 16.6 1200 - 2100
M2MY44K9W1LEM White Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 2638.57 26.5 2200 - 3100
M2MY44K9W1LEP White Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 2638.57 26.5 2200 - 3100
M2WY24K9W1LEM White Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 708.82 8.4 600 - 1100
M2WY24K9W1LEP White Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 708.82 8.4 600 - 1100
M2WY34K9W1LEM White Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 1405.19 16.6 1200 - 2100
M2WY34K9W1LEP White Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 1405.19 16.6 1200 - 2100
M2WY44K9W1LEM White Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 2075.83 26.5 1200 - 2100
M2WY44K9W1LEP White Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 2075.83 26.5 1200 - 2100
M2MH24K9W1LEM White Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 858.22 8.4 600 - 1100
M2MH24K9W1LEP White Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 858.22 8.4 600 - 1100
M2MH34K9W1LEM White Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 1701.5 16.6 1200 - 2100
M2MH34K9W1LEP White Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 1701.5 16.6 1200 - 2100
M2MH44K9W1LEM White Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 2638.57 26.5 2200 - 3100
M2MH44K9W1LEP White Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 2638.57 26.5 2200 - 3100
M2WH24K9W1LEM White Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 708.82 8.4 600 - 1100
M2WH24K9W1LEP White Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 708.82 8.4 600 - 1100
M2WH34K9W1LEM White Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 1405.19 16.6 1200 - 2100
M2WH34K9W1LEP White Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 1405.19 16.6 1200 - 2100
M2WH44K9W1LEM White Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 2075.83 26.5 1200 - 2100
M2WH44K9W1LEP White Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 2075.83 26.5 1200 - 2100
M2MY23K9W1LEM White Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 796.18 8.4 600 - 1100
M2MY23K9W1LEP White Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 796.18 8.4 600 - 1100
M2MY33K9W1LEM White Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 1578.5 16.6 1200 - 2100
M2MY33K9W1LEP White Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 1578.5 16.6 1200 - 2100
M2MY43K9W1LEM White Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 2447.83 26.5 2200 - 3100
M2MY43K9W1LEP White Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 2447.83 26.5 2200 - 3100
M2WY23K9W1LEM White Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 657.58 8.4 600 - 1100
M2WY23K9W1LEP White Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 657.58 8.4 600 - 1100
M2WY33K9W1LEM White Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 1303.61 16.6 1200 - 2100
M2WY33K9W1LEP White Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 1303.61 16.6 1200 - 2100
M2WY43K9W1LEM White Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 1925.77 26.5 1200 - 2100
M2WY43K9W1LEP White Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 1925.77 26.5 1200 - 2100
M2MH23K9W1LEM White Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 796.18 8.4 600 - 1100
M2MH23K9W1LEP White Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 796.18 8.4 600 - 1100
M2MH33K9W1LEM White Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 1578.5 16.6 1200 - 2100
M2MH33K9W1LEP White Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 1578.5 16.6 1200 - 2100
M2MH43K9W1LEM White Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 2447.83 26.5 2200 - 3100
M2MH43K9W1LEP White Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 2447.83 26.5 2200 - 3100
M2WH23K9W1LEM White Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 657.58 8.4 600 - 1100
M2WH23K9W1LEP White Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 657.58 8.4 600 - 1100
M2WH33K9W1LEM White Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 1303.61 16.6 1200 - 2100
M2WH33K9W1LEP White Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 1303.61 16.6 1200 - 2100
M2WH43K9W1LEM White Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 1925.77 26.5 1200 - 2100
M2WH43K9W1LEP White Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 1925.77 26.5 1200 - 2100

Click on part code below for downloads

Part Code Product Colour Colour Temperature Driver Type Emergency Type Distribution Length / Diameter (mm) Output (lm) Power (W) Nominal Lumens
M2MY24K8B2 Black Reflector,Black Bezel 4000K, Ra80 DALI LED Driver N/A Medium 119 753 8.4 600 - 1100
M2MY34K8B2 Black Reflector,Black Bezel 4000K, Ra80 DALI LED Driver N/A Medium 119 1487 16.6 1200 - 2100
M2MY44K8B2 Black Reflector,Black Bezel 4000K, Ra80 DALI LED Driver N/A Medium 119 2267 26.5 2200 - 3100
M2WY24K8B2 Black Reflector,Black Bezel 4000K, Ra80 DALI LED Driver N/A Wide 119 375 8.4 200 - 600
M2WY34K8B2 Black Reflector,Black Bezel 4000K, Ra80 DALI LED Driver N/A Wide 119 727 16.6 600 - 1100
M2WY44K8B2 Black Reflector,Black Bezel 4000K, Ra80 DALI LED Driver N/A Wide 119 1103 26.5 600 - 1100
M2MH24K8B2 Black Reflector,Black Bezel 4000K, Ra80 Fixed Output N/A Medium 119 753 8.4 600 - 1100
M2MH34K8B2 Black Reflector,Black Bezel 4000K, Ra80 Fixed Output N/A Medium 119 1487 16.6 1200 - 2100
M2MH44K8B2 Black Reflector,Black Bezel 4000K, Ra80 Fixed Output N/A Medium 119 2267 26.5 2200 - 3100
M2WH24K8B2 Black Reflector,Black Bezel 4000K, Ra80 Fixed Output N/A Wide 119 375 8.4 200 - 600
M2WH34K8B2 Black Reflector,Black Bezel 4000K, Ra80 Fixed Output N/A Wide 119 727 16.6 600 - 1100
M2WH44K8B2 Black Reflector,Black Bezel 4000K, Ra80 Fixed Output N/A Wide 119 1103 26.5 600 - 1100
M2MY23K8B2 Black Reflector,Black Bezel 3000K, RA80 DALI LED Driver N/A Medium 119 700.29 8.4 600 - 1100
M2MY33K8B2 Black Reflector,Black Bezel 3000K, RA80 DALI LED Driver N/A Medium 119 1382.91 16.6 1200 - 2100
M2MY43K8B2 Black Reflector,Black Bezel 3000K, RA80 DALI LED Driver N/A Medium 119 2108.31 26.5 1200 - 2100
M2WY23K8B2 Black Reflector,Black Bezel 3000K, RA80 DALI LED Driver N/A Wide 119 348.75 8.4 200 - 600
M2WY33K8B2 Black Reflector,Black Bezel 3000K, RA80 DALI LED Driver N/A Wide 119 676.11 16.6 600 - 1100
M2WY43K8B2 Black Reflector,Black Bezel 3000K, RA80 DALI LED Driver N/A Wide 119 1025.79 26.5 600 - 1100
M2MH23K8B2 Black Reflector,Black Bezel 3000K, RA80 Fixed Output N/A Medium 119 700.29 8.4 600 - 1100
M2MH33K8B2 Black Reflector,Black Bezel 3000K, RA80 Fixed Output N/A Medium 119 1382.91 16.6 1200 - 2100
M2MH43K8B2 Black Reflector,Black Bezel 3000K, RA80 Fixed Output N/A Medium 119 2108.31 26.5 1200 - 2100
M2WH23K8B2 Black Reflector,Black Bezel 3000K, RA80 Fixed Output N/A Wide 119 348.75 8.4 200 - 600
M2WH33K8B2 Black Reflector,Black Bezel 3000K, RA80 Fixed Output N/A Wide 119 676.11 16.6 600 - 1100
M2WH43K8B2 Black Reflector,Black Bezel 3000K, RA80 Fixed Output N/A Wide 119 1025.79 26.5 600 - 1100
M2MY24K9B2 Black Reflector,Black Bezel 4000K, Ra90 DALI LED Driver N/A Medium 119 624.99 8.4 600 - 1100
M2MY34K9B2 Black Reflector,Black Bezel 4000K, Ra90 DALI LED Driver N/A Medium 119 1234.21 16.6 1200 - 2100
M2MY44K9B2 Black Reflector,Black Bezel 4000K, Ra90 DALI LED Driver N/A Medium 119 1881.61 26.5 1200 - 2100
M2WY24K9B2 Black Reflector,Black Bezel 4000K, Ra90 DALI LED Driver N/A Wide 119 311.25 8.4 200 - 600
M2WY34K9B2 Black Reflector,Black Bezel 4000K, Ra90 DALI LED Driver N/A Wide 119 603.41 16.6 200 - 600
M2WY44K9B2 Black Reflector,Black Bezel 4000K, Ra90 DALI LED Driver N/A Wide 119 915.49 26.5 600 - 1100
M2MH24K9B2 Black Reflector,Black Bezel 4000K, Ra90 Fixed Output N/A Medium 119 624.99 8.4 600 - 1100
M2MH34K9B2 Black Reflector,Black Bezel 4000K, Ra90 Fixed Output N/A Medium 119 1234.21 16.6 1200 - 2100
M2MH44K9B2 Black Reflector,Black Bezel 4000K, Ra90 Fixed Output N/A Medium 119 1881.61 26.5 1200 - 2100
M2WH24K9B2 Black Reflector,Black Bezel 4000K, Ra90 Fixed Output N/A Wide 119 311.25 8.4 200 - 600
M2WH34K9B2 Black Reflector,Black Bezel 4000K, Ra90 Fixed Output N/A Wide 119 603.41 16.6 200 - 600
M2WH44K9B2 Black Reflector,Black Bezel 4000K, Ra90 Fixed Output N/A Wide 119 915.49 26.5 600 - 1100
M2MY23K9B2 Black Reflector,Black Bezel 3000K, RA90 DALI LED Driver N/A Medium 119 579.81 8.4 200 - 600
M2MY33K9B2 Black Reflector,Black Bezel 3000K, RA90 DALI LED Driver N/A Medium 119 1144.99 16.6 600 - 1100
M2MY43K9B2 Black Reflector,Black Bezel 3000K, RA90 DALI LED Driver N/A Medium 119 1745.59 26.5 1200 - 2100
M2WY23K9B2 Black Reflector,Black Bezel 3000K, RA90 DALI LED Driver N/A Wide 119 288.75 8.4 200 - 600
M2WY33K9B2 Black Reflector,Black Bezel 3000K, RA90 DALI LED Driver N/A Wide 119 559.79 16.6 200 - 600
M2WY43K9B2 Black Reflector,Black Bezel 3000K, RA90 DALI LED Driver N/A Wide 119 849.31 26.5 600 - 1100
M2MH23K9B2 Black Reflector,Black Bezel 3000K, RA90 Fixed Output N/A Medium 119 579.81 8.4 200 - 600
M2MH33K9B2 Black Reflector,Black Bezel 3000K, RA90 Fixed Output N/A Medium 119 1144.99 16.6 600 - 1100
M2MH43K9B2 Black Reflector,Black Bezel 3000K, RA90 Fixed Output N/A Medium 119 1745.59 26.5 1200 - 2100
M2WH23K9B2 Black Reflector,Black Bezel 3000K, RA90 Fixed Output N/A Wide 119 288.75 8.4 200 - 600
M2WH33K9B2 Black Reflector,Black Bezel 3000K, RA90 Fixed Output N/A Wide 119 559.79 16.6 200 - 600
M2WH43K9B2 Black Reflector,Black Bezel 3000K, RA90 Fixed Output N/A Wide 119 849.31 26.5 600 - 1100
M2MY24K8B2LEM Black Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 753 8.4 600 - 1100
M2MY24K8B2LEP Black Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 753 8.4 600 - 1100
M2MY34K8B2LEM Black Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 1487 16.6 1200 - 2100
M2MY34K8B2LEP Black Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 1487 16.6 1200 - 2100
M2MY44K8B2LEM Black Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 2267 26.5 2200 - 3100
M2MY44K8B2LEP Black Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 2267 26.5 2200 - 3100
M2WY24K8B2LEM Black Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 375 8.4 200 - 600
M2WY24K8B2LEP Black Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 375 8.4 200 - 600
M2WY34K8B2LEM Black Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 727 16.6 600 - 1100
M2WY34K8B2LEP Black Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 727 16.6 600 - 1100
M2WY44K8B2LEM Black Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 1103 26.5 600 - 1100
M2WY44K8B2LEP Black Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 1103 26.5 600 - 1100
M2MH24K8B2LEM Black Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 753 8.4 600 - 1100
M2MH24K8B2LEP Black Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 753 8.4 600 - 1100
M2MH34K8B2LEM Black Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 1487 16.6 1200 - 2100
M2MH34K8B2LEP Black Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 1487 16.6 1200 - 2100
M2MH44K8B2LEM Black Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 2267 26.5 2200 - 3100
M2MH44K8B2LEP Black Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 2267 26.5 2200 - 3100
M2WH24K8B2LEM Black Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 375 8.4 200 - 600
M2WH24K8B2LEP Black Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 375 8.4 200 - 600
M2WH34K8B2LEM Black Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 727 16.6 600 - 1100
M2WH34K8B2LEP Black Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 727 16.6 600 - 1100
M2WH44K8B2LEM Black Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 1103 26.5 600 - 1100
M2WH44K8B2LEP Black Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 1103 26.5 600 - 1100
M2MY23K8B2LEM Black Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 700.29 8.4 600 - 1100
M2MY23K8B2LEP Black Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 700.29 8.4 600 - 1100
M2MY33K8B2LEM Black Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 1382.91 16.6 1200 - 2100
M2MY33K8B2LEP Black Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 1382.91 16.6 1200 - 2100
M2MY43K8B2LEM Black Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 2108.31 26.5 1200 - 2100
M2MY43K8B2LEP Black Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 2108.31 26.5 1200 - 2100
M2WY23K8B2LEM Black Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 348.75 8.4 200 - 600
M2WY23K8B2LEP Black Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 348.75 8.4 200 - 600
M2WY33K8B2LEM Black Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 676.11 16.6 600 - 1100
M2WY33K8B2LEP Black Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 676.11 16.6 600 - 1100
M2WY43K8B2LEM Black Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 1025.79 26.5 600 - 1100
M2WY43K8B2LEP Black Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 1025.79 26.5 600 - 1100
M2MH23K8B2LEM Black Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 700.29 8.4 600 - 1100
M2MH23K8B2LEP Black Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 700.29 8.4 600 - 1100
M2MH33K8B2LEM Black Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 1382.91 16.6 1200 - 2100
M2MH33K8B2LEP Black Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 1382.91 16.6 1200 - 2100
M2MH43K8B2LEM Black Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 2108.31 26.5 1200 - 2100
M2MH43K8B2LEP Black Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 2108.31 26.5 1200 - 2100
M2WH23K8B2LEM Black Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 348.75 8.4 200 - 600
M2WH23K8B2LEP Black Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 348.75 8.4 200 - 600
M2WH33K8B2LEM Black Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 676.11 16.6 600 - 1100
M2WH33K8B2LEP Black Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 676.11 16.6 600 - 1100
M2WH43K8B2LEM Black Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 1025.79 26.5 600 - 1100
M2WH43K8B2LEP Black Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 1025.79 26.5 600 - 1100
M2MY24K9B2LEM Black Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 624.99 8.4 600 - 1100
M2MY24K9B2LEP Black Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 624.99 8.4 600 - 1100
M2MY34K9B2LEM Black Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 1234.21 16.6 1200 - 2100
M2MY34K9B2LEP Black Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 1234.21 16.6 1200 - 2100
M2MY44K9B2LEM Black Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 1881.61 26.5 1200 - 2100
M2MY44K9B2LEP Black Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 1881.61 26.5 1200 - 2100
M2WY24K9B2LEM Black Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 311.25 8.4 200 - 600
M2WY24K9B2LEP Black Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 311.25 8.4 200 - 600
M2WY34K9B2LEM Black Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 603.41 16.6 200 - 600
M2WY34K9B2LEP Black Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 603.41 16.6 200 - 600
M2WY44K9B2LEM Black Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 915.49 26.5 600 - 1100
M2WY44K9B2LEP Black Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 915.49 26.5 600 - 1100
M2MH24K9B2LEM Black Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 624.99 8.4 600 - 1100
M2MH24K9B2LEP Black Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 624.99 8.4 600 - 1100
M2MH34K9B2LEM Black Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 1234.21 16.6 1200 - 2100
M2MH34K9B2LEP Black Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 1234.21 16.6 1200 - 2100
M2MH44K9B2LEM Black Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 1881.61 26.5 1200 - 2100
M2MH44K9B2LEP Black Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 1881.61 26.5 1200 - 2100
M2WH24K9B2LEM Black Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 311.25 8.4 200 - 600
M2WH24K9B2LEP Black Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 311.25 8.4 200 - 600
M2WH34K9B2LEM Black Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 603.41 16.6 200 - 600
M2WH34K9B2LEP Black Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 603.41 16.6 200 - 600
M2WH44K9B2LEM Black Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 915.49 26.5 600 - 1100
M2WH44K9B2LEP Black Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 915.49 26.5 600 - 1100
M2MY23K9B2LEM Black Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 579.81 8.4 200 - 600
M2MY23K9B2LEP Black Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 579.81 8.4 200 - 600
M2MY33K9B2LEM Black Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 1144.99 16.6 600 - 1100
M2MY33K9B2LEP Black Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 1144.99 16.6 600 - 1100
M2MY43K9B2LEM Black Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 1745.59 26.5 1200 - 2100
M2MY43K9B2LEP Black Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 1745.59 26.5 1200 - 2100
M2WY23K9B2LEM Black Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 288.75 8.4 200 - 600
M2WY23K9B2LEP Black Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 288.75 8.4 200 - 600
M2WY33K9B2LEM Black Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 559.79 16.6 200 - 600
M2WY33K9B2LEP Black Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 559.79 16.6 200 - 600
M2WY43K9B2LEM Black Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 849.31 26.5 600 - 1100
M2WY43K9B2LEP Black Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 849.31 26.5 600 - 1100
M2MH23K9B2LEM Black Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 579.81 8.4 200 - 600
M2MH23K9B2LEP Black Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 579.81 8.4 200 - 600
M2MH33K9B2LEM Black Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 1144.99 16.6 600 - 1100
M2MH33K9B2LEP Black Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 1144.99 16.6 600 - 1100
M2MH43K9B2LEM Black Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 1745.59 26.5 1200 - 2100
M2MH43K9B2LEP Black Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 1745.59 26.5 1200 - 2100
M2WH23K9B2LEM Black Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 288.75 8.4 200 - 600
M2WH23K9B2LEP Black Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 288.75 8.4 200 - 600
M2WH33K9B2LEM Black Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 559.79 16.6 200 - 600
M2WH33K9B2LEP Black Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 559.79 16.6 200 - 600
M2WH43K9B2LEM Black Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 849.31 26.5 600 - 1100
M2WH43K9B2LEP Black Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 849.31 26.5 600 - 1100

Click on part code below for downloads

Part Code Product Colour Colour Temperature Driver Type Emergency Type Distribution Length / Diameter (mm) Output (lm) Power (W) Nominal Lumens
M2MY24K8S1 Specular Reflector,White Bezel 4000K, Ra80 DALI LED Driver N/A Medium 119 1012 8.4 600 - 1100
M2MY34K8S1 Specular Reflector,White Bezel 4000K, Ra80 DALI LED Driver N/A Medium 119 1996 16.6 1200 - 2100
M2MY44K8S1 Specular Reflector,White Bezel 4000K, Ra80 DALI LED Driver N/A Medium 119 3117 26.5 2200 - 3100
M2WY24K8S1 Specular Reflector,White Bezel 4000K, Ra80 DALI LED Driver N/A Wide 119 876 8.4 600 - 1100
M2WY34K8S1 Specular Reflector,White Bezel 4000K, Ra80 DALI LED Driver N/A Wide 119 1716 16.6 1200 - 2100
M2WY44K8S1 Specular Reflector,White Bezel 4000K, Ra80 DALI LED Driver N/A Wide 119 2600 26.5 2200 - 3100
M2MH24K8S1 Specular Reflector,White Bezel 4000K, Ra80 Fixed Output N/A Medium 119 1012 8.4 600 - 1100
M2MH34K8S1 Specular Reflector,White Bezel 4000K, Ra80 Fixed Output N/A Medium 119 1996 16.6 1200 - 2100
M2MH44K8S1 Specular Reflector,White Bezel 4000K, Ra80 Fixed Output N/A Medium 119 3117 26.5 2200 - 3100
M2WH24K8S1 Specular Reflector,White Bezel 4000K, Ra80 Fixed Output N/A Wide 119 876 8.4 600 - 1100
M2WH34K8S1 Specular Reflector,White Bezel 4000K, Ra80 Fixed Output N/A Wide 119 1716 16.6 1200 - 2100
M2WH44K8S1 Specular Reflector,White Bezel 4000K, Ra80 Fixed Output N/A Wide 119 2600 26.5 2200 - 3100
M2MY23K8S1 Specular Reflector,White Bezel 3000K, RA80 DALI LED Driver N/A Medium 119 941.16 8.4 600 - 1100
M2MY33K8S1 Specular Reflector,White Bezel 3000K, RA80 DALI LED Driver N/A Medium 119 1856.28 16.6 1200 - 2100
M2MY43K8S1 Specular Reflector,White Bezel 3000K, RA80 DALI LED Driver N/A Medium 119 2898.81 26.5 2200 - 3100
M2WY23K8S1 Specular Reflector,White Bezel 3000K, RA80 DALI LED Driver N/A Wide 119 814.68 8.4 600 - 1100
M2WY33K8S1 Specular Reflector,White Bezel 3000K, RA80 DALI LED Driver N/A Wide 119 1595.88 16.6 1200 - 2100
M2WY43K8S1 Specular Reflector,White Bezel 3000K, RA80 DALI LED Driver N/A Wide 119 2418 26.5 2200 - 3100
M2MH23K8S1 Specular Reflector,White Bezel 3000K, RA80 Fixed Output N/A Medium 119 941.16 8.4 600 - 1100
M2MH33K8S1 Specular Reflector,White Bezel 3000K, RA80 Fixed Output N/A Medium 119 1856.28 16.6 1200 - 2100
M2MH43K8S1 Specular Reflector,White Bezel 3000K, RA80 Fixed Output N/A Medium 119 2898.81 26.5 2200 - 3100
M2WH23K8S1 Specular Reflector,White Bezel 3000K, RA80 Fixed Output N/A Wide 119 814.68 8.4 600 - 1100
M2WH33K8S1 Specular Reflector,White Bezel 3000K, RA80 Fixed Output N/A Wide 119 1595.88 16.6 1200 - 2100
M2WH43K8S1 Specular Reflector,White Bezel 3000K, RA80 Fixed Output N/A Wide 119 2418 26.5 2200 - 3100
M2MY24K9S1 Specular Reflector,White Bezel 4000K, Ra90 DALI LED Driver N/A Medium 119 839.96 8.4 600 - 1100
M2MY34K9S1 Specular Reflector,White Bezel 4000K, Ra90 DALI LED Driver N/A Medium 119 1656.68 16.6 1200 - 2100
M2MY44K9S1 Specular Reflector,White Bezel 4000K, Ra90 DALI LED Driver N/A Medium 119 2587.11 26.5 2200 - 3100
M2WY24K9S1 Specular Reflector,White Bezel 4000K, Ra90 DALI LED Driver N/A Wide 119 727.08 8.4 600 - 1100
M2WY34K9S1 Specular Reflector,White Bezel 4000K, Ra90 DALI LED Driver N/A Wide 119 1424.28 16.6 1200 - 2100
M2WY44K9S1 Specular Reflector,White Bezel 4000K, Ra90 DALI LED Driver N/A Wide 119 2158 26.5 1200 - 2100
M2MH24K9S1 Specular Reflector,White Bezel 4000K, Ra90 Fixed Output N/A Medium 119 839.96 8.4 600 - 1100
M2MH34K9S1 Specular Reflector,White Bezel 4000K, Ra90 Fixed Output N/A Medium 119 1656.68 16.6 1200 - 2100
M2MH44K9S1 Specular Reflector,White Bezel 4000K, Ra90 Fixed Output N/A Medium 119 2587.11 26.5 2200 - 3100
M2WH24K9S1 Specular Reflector,White Bezel 4000K, Ra90 Fixed Output N/A Wide 119 727.08 8.4 600 - 1100
M2WH34K9S1 Specular Reflector,White Bezel 4000K, Ra90 Fixed Output N/A Wide 119 1424.28 16.6 1200 - 2100
M2WH44K9S1 Specular Reflector,White Bezel 4000K, Ra90 Fixed Output N/A Wide 119 2158 26.5 1200 - 2100
M2MY23K9S1 Specular Reflector,White Bezel 3000K, RA90 DALI LED Driver N/A Medium 119 779.24 8.4 600 - 1100
M2MY33K9S1 Specular Reflector,White Bezel 3000K, RA90 DALI LED Driver N/A Medium 119 1536.92 16.6 1200 - 2100
M2MY43K9S1 Specular Reflector,White Bezel 3000K, RA90 DALI LED Driver N/A Medium 119 2400.09 26.5 2200 - 3100
M2WY23K9S1 Specular Reflector,White Bezel 3000K, RA90 DALI LED Driver N/A Wide 119 674.52 8.4 600 - 1100
M2WY33K9S1 Specular Reflector,White Bezel 3000K, RA90 DALI LED Driver N/A Wide 119 1321.32 16.6 1200 - 2100
M2WY43K9S1 Specular Reflector,White Bezel 3000K, RA90 DALI LED Driver N/A Wide 119 2002 26.5 1200 - 2100
M2MH23K9S1 Specular Reflector,White Bezel 3000K, RA90 Fixed Output N/A Medium 119 779.24 8.4 600 - 1100
M2MH33K9S1 Specular Reflector,White Bezel 3000K, RA90 Fixed Output N/A Medium 119 1536.92 16.6 1200 - 2100
M2MH43K9S1 Specular Reflector,White Bezel 3000K, RA90 Fixed Output N/A Medium 119 2400.09 26.5 2200 - 3100
M2WH23K9S1 Specular Reflector,White Bezel 3000K, RA90 Fixed Output N/A Wide 119 674.52 8.4 600 - 1100
M2WH33K9S1 Specular Reflector,White Bezel 3000K, RA90 Fixed Output N/A Wide 119 1321.32 16.6 1200 - 2100
M2WH43K9S1 Specular Reflector,White Bezel 3000K, RA90 Fixed Output N/A Wide 119 2002 26.5 1200 - 2100
M2MY24K8S2 Specular Reflector,Black Bezel 4000K, Ra80 DALI LED Driver N/A Medium 119 1012 8.4 600 - 1100
M2MY34K8S2 Specular Reflector,Black Bezel 4000K, Ra80 DALI LED Driver N/A Medium 119 1996 16.6 1200 - 2100
M2MY44K8S2 Specular Reflector,Black Bezel 4000K, Ra80 DALI LED Driver N/A Medium 119 3117 26.5 2200 - 3100
M2WY24K8S2 Specular Reflector,Black Bezel 4000K, Ra80 DALI LED Driver N/A Wide 119 876 8.4 600 - 1100
M2WY34K8S2 Specular Reflector,Black Bezel 4000K, Ra80 DALI LED Driver N/A Wide 119 1716 16.6 1200 - 2100
M2WY44K8S2 Specular Reflector,Black Bezel 4000K, Ra80 DALI LED Driver N/A Wide 119 2600 26.5 2200 - 3100
M2MH24K8S2 Specular Reflector,Black Bezel 4000K, Ra80 Fixed Output N/A Medium 119 1012 8.4 600 - 1100
M2MH34K8S2 Specular Reflector,Black Bezel 4000K, Ra80 Fixed Output N/A Medium 119 1996 16.6 1200 - 2100
M2MH44K8S2 Specular Reflector,Black Bezel 4000K, Ra80 Fixed Output N/A Medium 119 3117 26.5 2200 - 3100
M2WH24K8S2 Specular Reflector,Black Bezel 4000K, Ra80 Fixed Output N/A Wide 119 876 8.4 600 - 1100
M2WH34K8S2 Specular Reflector,Black Bezel 4000K, Ra80 Fixed Output N/A Wide 119 1716 16.6 1200 - 2100
M2WH44K8S2 Specular Reflector,Black Bezel 4000K, Ra80 Fixed Output N/A Wide 119 2600 26.5 2200 - 3100
M2MY23K8S2 Specular Reflector,Black Bezel 3000K, RA80 DALI LED Driver N/A Medium 119 941.16 8.4 600 - 1100
M2MY33K8S2 Specular Reflector,Black Bezel 3000K, RA80 DALI LED Driver N/A Medium 119 1856.28 16.6 1200 - 2100
M2MY43K8S2 Specular Reflector,Black Bezel 3000K, RA80 DALI LED Driver N/A Medium 119 2898.81 26.5 2200 - 3100
M2WY23K8S2 Specular Reflector,Black Bezel 3000K, RA80 DALI LED Driver N/A Wide 119 814.68 8.4 600 - 1100
M2WY33K8S2 Specular Reflector,Black Bezel 3000K, RA80 DALI LED Driver N/A Wide 119 1595.88 16.6 1200 - 2100
M2WY43K8S2 Specular Reflector,Black Bezel 3000K, RA80 DALI LED Driver N/A Wide 119 2418 26.5 2200 - 3100
M2MH23K8S2 Specular Reflector,Black Bezel 3000K, RA80 Fixed Output N/A Medium 119 941.16 8.4 600 - 1100
M2MH33K8S2 Specular Reflector,Black Bezel 3000K, RA80 Fixed Output N/A Medium 119 1856.28 16.6 1200 - 2100
M2MH43K8S2 Specular Reflector,Black Bezel 3000K, RA80 Fixed Output N/A Medium 119 2898.81 26.5 2200 - 3100
M2WH23K8S2 Specular Reflector,Black Bezel 3000K, RA80 Fixed Output N/A Wide 119 814.68 8.4 600 - 1100
M2WH33K8S2 Specular Reflector,Black Bezel 3000K, RA80 Fixed Output N/A Wide 119 1595.88 16.6 1200 - 2100
M2WH43K8S2 Specular Reflector,Black Bezel 3000K, RA80 Fixed Output N/A Wide 119 2418 26.5 2200 - 3100
M2MY24K9S2 Specular Reflector,Black Bezel 4000K, Ra90 DALI LED Driver N/A Medium 119 839.96 8.4 600 - 1100
M2MY34K9S2 Specular Reflector,Black Bezel 4000K, Ra90 DALI LED Driver N/A Medium 119 1656.68 16.6 1200 - 2100
M2MY44K9S2 Specular Reflector,Black Bezel 4000K, Ra90 DALI LED Driver N/A Medium 119 2587.11 26.5 2200 - 3100
M2WY24K9S2 Specular Reflector,Black Bezel 4000K, Ra90 DALI LED Driver N/A Wide 119 727.08 8.4 600 - 1100
M2WY34K9S2 Specular Reflector,Black Bezel 4000K, Ra90 DALI LED Driver N/A Wide 119 1424.28 16.6 1200 - 2100
M2WY44K9S2 Specular Reflector,Black Bezel 4000K, Ra90 DALI LED Driver N/A Wide 119 2158 26.5 1200 - 2100
M2MH24K9S2 Specular Reflector,Black Bezel 4000K, Ra90 Fixed Output N/A Medium 119 839.96 8.4 600 - 1100
M2MH34K9S2 Specular Reflector,Black Bezel 4000K, Ra90 Fixed Output N/A Medium 119 1656.68 16.6 1200 - 2100
M2MH44K9S2 Specular Reflector,Black Bezel 4000K, Ra90 Fixed Output N/A Medium 119 2587.11 26.5 2200 - 3100
M2WH24K9S2 Specular Reflector,Black Bezel 4000K, Ra90 Fixed Output N/A Wide 119 727.08 8.4 600 - 1100
M2WH34K9S2 Specular Reflector,Black Bezel 4000K, Ra90 Fixed Output N/A Wide 119 1424.28 16.6 1200 - 2100
M2WH44K9S2 Specular Reflector,Black Bezel 4000K, Ra90 Fixed Output N/A Wide 119 2158 26.5 1200 - 2100
M2MY23K9S2 Specular Reflector,Black Bezel 3000K, RA90 DALI LED Driver N/A Medium 119 779.24 8.4 600 - 1100
M2MY33K9S2 Specular Reflector,Black Bezel 3000K, RA90 DALI LED Driver N/A Medium 119 1536.92 16.6 1200 - 2100
M2MY43K9S2 Specular Reflector,Black Bezel 3000K, RA90 DALI LED Driver N/A Medium 119 2400.09 26.5 2200 - 3100
M2WY23K9S2 Specular Reflector,Black Bezel 3000K, RA90 DALI LED Driver N/A Wide 119 674.52 8.4 600 - 1100
M2WY33K9S2 Specular Reflector,Black Bezel 3000K, RA90 DALI LED Driver N/A Wide 119 1321.32 16.6 1200 - 2100
M2WY43K9S2 Specular Reflector,Black Bezel 3000K, RA90 DALI LED Driver N/A Wide 119 2002 26.5 1200 - 2100
M2MH23K9S2 Specular Reflector,Black Bezel 3000K, RA90 Fixed Output N/A Medium 119 779.24 8.4 600 - 1100
M2MH33K9S2 Specular Reflector,Black Bezel 3000K, RA90 Fixed Output N/A Medium 119 1536.92 16.6 1200 - 2100
M2MH43K9S2 Specular Reflector,Black Bezel 3000K, RA90 Fixed Output N/A Medium 119 2400.09 26.5 2200 - 3100
M2WH23K9S2 Specular Reflector,Black Bezel 3000K, RA90 Fixed Output N/A Wide 119 674.52 8.4 600 - 1100
M2WH33K9S2 Specular Reflector,Black Bezel 3000K, RA90 Fixed Output N/A Wide 119 1321.32 16.6 1200 - 2100
M2WH43K9S2 Specular Reflector,Black Bezel 3000K, RA90 Fixed Output N/A Wide 119 2002 26.5 1200 - 2100
M2MY24K8S1LEM Specular Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 1012 8.4 600 - 1100
M2MY24K8S1LEP Specular Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 1012 8.4 600 - 1100
M2MY34K8S1LEM Specular Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 1996 16.6 1200 - 2100
M2MY34K8S1LEP Specular Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 1996 16.6 1200 - 2100
M2MY44K8S1LEM Specular Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 3117 26.5 2200 - 3100
M2MY44K8S1LEP Specular Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 3117 26.5 2200 - 3100
M2WY24K8S1LEM Specular Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 876 8.4 600 - 1100
M2WY24K8S1LEP Specular Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 876 8.4 600 - 1100
M2WY34K8S1LEM Specular Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 1716 16.6 1200 - 2100
M2WY34K8S1LEP Specular Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 1716 16.6 1200 - 2100
M2WY44K8S1LEM Specular Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 2600 26.5 2200 - 3100
M2WY44K8S1LEP Specular Reflector,White Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 2600 26.5 2200 - 3100
M2MH24K8S1LEM Specular Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 1012 8.4 600 - 1100
M2MH24K8S1LEP Specular Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 1012 8.4 600 - 1100
M2MH34K8S1LEM Specular Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 1996 16.6 1200 - 2100
M2MH34K8S1LEP Specular Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 1996 16.6 1200 - 2100
M2MH44K8S1LEM Specular Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 3117 26.5 2200 - 3100
M2MH44K8S1LEP Specular Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 3117 26.5 2200 - 3100
M2WH24K8S1LEM Specular Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 876 8.4 600 - 1100
M2WH24K8S1LEP Specular Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 876 8.4 600 - 1100
M2WH34K8S1LEM Specular Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 1716 16.6 1200 - 2100
M2WH34K8S1LEP Specular Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 1716 16.6 1200 - 2100
M2WH44K8S1LEM Specular Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 2600 26.5 2200 - 3100
M2WH44K8S1LEP Specular Reflector,White Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 2600 26.5 2200 - 3100
M2MY23K8S1LEM Specular Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 941.16 8.4 600 - 1100
M2MY23K8S1LEP Specular Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 941.16 8.4 600 - 1100
M2MY33K8S1LEM Specular Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 1856.28 16.6 1200 - 2100
M2MY33K8S1LEP Specular Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 1856.28 16.6 1200 - 2100
M2MY43K8S1LEM Specular Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 2898.81 26.5 2200 - 3100
M2MY43K8S1LEP Specular Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 2898.81 26.5 2200 - 3100
M2WY23K8S1LEM Specular Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 814.68 8.4 600 - 1100
M2WY23K8S1LEP Specular Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 814.68 8.4 600 - 1100
M2WY33K8S1LEM Specular Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 1595.88 16.6 1200 - 2100
M2WY33K8S1LEP Specular Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 1595.88 16.6 1200 - 2100
M2WY43K8S1LEM Specular Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 2418 26.5 2200 - 3100
M2WY43K8S1LEP Specular Reflector,White Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 2418 26.5 2200 - 3100
M2MH23K8S1LEM Specular Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 941.16 8.4 600 - 1100
M2MH23K8S1LEP Specular Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 941.16 8.4 600 - 1100
M2MH33K8S1LEM Specular Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 1856.28 16.6 1200 - 2100
M2MH33K8S1LEP Specular Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 1856.28 16.6 1200 - 2100
M2MH43K8S1LEM Specular Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 2898.81 26.5 2200 - 3100
M2MH43K8S1LEP Specular Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 2898.81 26.5 2200 - 3100
M2WH23K8S1LEM Specular Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 814.68 8.4 600 - 1100
M2WH23K8S1LEP Specular Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 814.68 8.4 600 - 1100
M2WH33K8S1LEM Specular Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 1595.88 16.6 1200 - 2100
M2WH33K8S1LEP Specular Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 1595.88 16.6 1200 - 2100
M2WH43K8S1LEM Specular Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 2418 26.5 2200 - 3100
M2WH43K8S1LEP Specular Reflector,White Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 2418 26.5 2200 - 3100
M2MY24K9S1LEM Specular Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 839.96 8.4 600 - 1100
M2MY24K9S1LEP Specular Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 839.96 8.4 600 - 1100
M2MY34K9S1LEM Specular Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 1656.68 16.6 1200 - 2100
M2MY34K9S1LEP Specular Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 1656.68 16.6 1200 - 2100
M2MY44K9S1LEM Specular Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 2587.11 26.5 2200 - 3100
M2MY44K9S1LEP Specular Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 2587.11 26.5 2200 - 3100
M2WY24K9S1LEM Specular Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 727.08 8.4 600 - 1100
M2WY24K9S1LEP Specular Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 727.08 8.4 600 - 1100
M2WY34K9S1LEM Specular Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 1424.28 16.6 1200 - 2100
M2WY34K9S1LEP Specular Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 1424.28 16.6 1200 - 2100
M2WY44K9S1LEM Specular Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 2158 26.5 1200 - 2100
M2WY44K9S1LEP Specular Reflector,White Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 2158 26.5 1200 - 2100
M2MH24K9S1LEM Specular Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 839.96 8.4 600 - 1100
M2MH24K9S1LEP Specular Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 839.96 8.4 600 - 1100
M2MH34K9S1LEM Specular Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 1656.68 16.6 1200 - 2100
M2MH34K9S1LEP Specular Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 1656.68 16.6 1200 - 2100
M2MH44K9S1LEM Specular Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 2587.11 26.5 2200 - 3100
M2MH44K9S1LEP Specular Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 2587.11 26.5 2200 - 3100
M2WH24K9S1LEM Specular Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 727.08 8.4 600 - 1100
M2WH24K9S1LEP Specular Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 727.08 8.4 600 - 1100
M2WH34K9S1LEM Specular Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 1424.28 16.6 1200 - 2100
M2WH34K9S1LEP Specular Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 1424.28 16.6 1200 - 2100
M2WH44K9S1LEM Specular Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 2158 26.5 1200 - 2100
M2WH44K9S1LEP Specular Reflector,White Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 2158 26.5 1200 - 2100
M2MY23K9S1LEM Specular Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 779.24 8.4 600 - 1100
M2MY23K9S1LEP Specular Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 779.24 8.4 600 - 1100
M2MY33K9S1LEM Specular Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 1536.92 16.6 1200 - 2100
M2MY33K9S1LEP Specular Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 1536.92 16.6 1200 - 2100
M2MY43K9S1LEM Specular Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 2400.09 26.5 2200 - 3100
M2MY43K9S1LEP Specular Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 2400.09 26.5 2200 - 3100
M2WY23K9S1LEM Specular Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 674.52 8.4 600 - 1100
M2WY23K9S1LEP Specular Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 674.52 8.4 600 - 1100
M2WY33K9S1LEM Specular Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 1321.32 16.6 1200 - 2100
M2WY33K9S1LEP Specular Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 1321.32 16.6 1200 - 2100
M2WY43K9S1LEM Specular Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 2002 26.5 1200 - 2100
M2WY43K9S1LEP Specular Reflector,White Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 2002 26.5 1200 - 2100
M2MH23K9S1LEM Specular Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 779.24 8.4 600 - 1100
M2MH23K9S1LEP Specular Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 779.24 8.4 600 - 1100
M2MH33K9S1LEM Specular Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 1536.92 16.6 1200 - 2100
M2MH33K9S1LEP Specular Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 1536.92 16.6 1200 - 2100
M2MH43K9S1LEM Specular Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 2400.09 26.5 2200 - 3100
M2MH43K9S1LEP Specular Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 2400.09 26.5 2200 - 3100
M2WH23K9S1LEM Specular Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 674.52 8.4 600 - 1100
M2WH23K9S1LEP Specular Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 674.52 8.4 600 - 1100
M2WH33K9S1LEM Specular Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 1321.32 16.6 1200 - 2100
M2WH33K9S1LEP Specular Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 1321.32 16.6 1200 - 2100
M2WH43K9S1LEM Specular Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 2002 26.5 1200 - 2100
M2WH43K9S1LEP Specular Reflector,White Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 2002 26.5 1200 - 2100
M2MY24K8S2LEM Specular Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 1012 8.4 600 - 1100
M2MY24K8S2LEP Specular Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 1012 8.4 600 - 1100
M2MY34K8S2LEM Specular Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 1996 16.6 1200 - 2100
M2MY34K8S2LEP Specular Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 1996 16.6 1200 - 2100
M2MY44K8S2LEM Specular Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 3117 26.5 2200 - 3100
M2MY44K8S2LEP Specular Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 3117 26.5 2200 - 3100
M2WY24K8S2LEM Specular Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 876 8.4 600 - 1100
M2WY24K8S2LEP Specular Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 876 8.4 600 - 1100
M2WY34K8S2LEM Specular Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 1716 16.6 1200 - 2100
M2WY34K8S2LEP Specular Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 1716 16.6 1200 - 2100
M2WY44K8S2LEM Specular Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EM LiFeP04 119 2600 26.5 2200 - 3100
M2WY44K8S2LEP Specular Reflector,Black Bezel 4000K, Ra80 DALI LED Driver 3 hr EP LiFeP04 119 2600 26.5 2200 - 3100
M2MH24K8S2LEM Specular Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 1012 8.4 600 - 1100
M2MH24K8S2LEP Specular Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 1012 8.4 600 - 1100
M2MH34K8S2LEM Specular Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 1996 16.6 1200 - 2100
M2MH34K8S2LEP Specular Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 1996 16.6 1200 - 2100
M2MH44K8S2LEM Specular Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 3117 26.5 2200 - 3100
M2MH44K8S2LEP Specular Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 3117 26.5 2200 - 3100
M2WH24K8S2LEM Specular Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 876 8.4 600 - 1100
M2WH24K8S2LEP Specular Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 876 8.4 600 - 1100
M2WH34K8S2LEM Specular Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 1716 16.6 1200 - 2100
M2WH34K8S2LEP Specular Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 1716 16.6 1200 - 2100
M2WH44K8S2LEM Specular Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EM LiFeP04 119 2600 26.5 2200 - 3100
M2WH44K8S2LEP Specular Reflector,Black Bezel 4000K, Ra80 Fixed Output 3 hr EP LiFeP04 119 2600 26.5 2200 - 3100
M2MY23K8S2LEM Specular Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 941.16 8.4 600 - 1100
M2MY23K8S2LEP Specular Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 941.16 8.4 600 - 1100
M2MY33K8S2LEM Specular Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 1856.28 16.6 1200 - 2100
M2MY33K8S2LEP Specular Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 1856.28 16.6 1200 - 2100
M2MY43K8S2LEM Specular Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 2898.81 26.5 2200 - 3100
M2MY43K8S2LEP Specular Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 2898.81 26.5 2200 - 3100
M2WY23K8S2LEM Specular Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 814.68 8.4 600 - 1100
M2WY23K8S2LEP Specular Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 814.68 8.4 600 - 1100
M2WY33K8S2LEM Specular Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 1595.88 16.6 1200 - 2100
M2WY33K8S2LEP Specular Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 1595.88 16.6 1200 - 2100
M2WY43K8S2LEM Specular Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EM LiFeP04 119 2418 26.5 2200 - 3100
M2WY43K8S2LEP Specular Reflector,Black Bezel 3000K, RA80 DALI LED Driver 3 hr EP LiFeP04 119 2418 26.5 2200 - 3100
M2MH23K8S2LEM Specular Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 941.16 8.4 600 - 1100
M2MH23K8S2LEP Specular Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 941.16 8.4 600 - 1100
M2MH33K8S2LEM Specular Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 1856.28 16.6 1200 - 2100
M2MH33K8S2LEP Specular Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 1856.28 16.6 1200 - 2100
M2MH43K8S2LEM Specular Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 2898.81 26.5 2200 - 3100
M2MH43K8S2LEP Specular Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 2898.81 26.5 2200 - 3100
M2WH23K8S2LEM Specular Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 814.68 8.4 600 - 1100
M2WH23K8S2LEP Specular Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 814.68 8.4 600 - 1100
M2WH33K8S2LEM Specular Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 1595.88 16.6 1200 - 2100
M2WH33K8S2LEP Specular Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 1595.88 16.6 1200 - 2100
M2WH43K8S2LEM Specular Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EM LiFeP04 119 2418 26.5 2200 - 3100
M2WH43K8S2LEP Specular Reflector,Black Bezel 3000K, RA80 Fixed Output 3 hr EP LiFeP04 119 2418 26.5 2200 - 3100
M2MY24K9S2LEM Specular Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 839.96 8.4 600 - 1100
M2MY24K9S2LEP Specular Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 839.96 8.4 600 - 1100
M2MY34K9S2LEM Specular Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 1656.68 16.6 1200 - 2100
M2MY34K9S2LEP Specular Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 1656.68 16.6 1200 - 2100
M2MY44K9S2LEM Specular Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 2587.11 26.5 2200 - 3100
M2MY44K9S2LEP Specular Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 2587.11 26.5 2200 - 3100
M2WY24K9S2LEM Specular Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 727.08 8.4 600 - 1100
M2WY24K9S2LEP Specular Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 727.08 8.4 600 - 1100
M2WY34K9S2LEM Specular Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 1424.28 16.6 1200 - 2100
M2WY34K9S2LEP Specular Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 1424.28 16.6 1200 - 2100
M2WY44K9S2LEM Specular Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EM LiFeP04 119 2158 26.5 1200 - 2100
M2WY44K9S2LEP Specular Reflector,Black Bezel 4000K, Ra90 DALI LED Driver 3 hr EP LiFeP04 119 2158 26.5 1200 - 2100
M2MH24K9S2LEM Specular Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 839.96 8.4 600 - 1100
M2MH24K9S2LEP Specular Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 839.96 8.4 600 - 1100
M2MH34K9S2LEM Specular Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 1656.68 16.6 1200 - 2100
M2MH34K9S2LEP Specular Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 1656.68 16.6 1200 - 2100
M2MH44K9S2LEM Specular Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 2587.11 26.5 2200 - 3100
M2MH44K9S2LEP Specular Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 2587.11 26.5 2200 - 3100
M2WH24K9S2LEM Specular Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 727.08 8.4 600 - 1100
M2WH24K9S2LEP Specular Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 727.08 8.4 600 - 1100
M2WH34K9S2LEM Specular Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 1424.28 16.6 1200 - 2100
M2WH34K9S2LEP Specular Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 1424.28 16.6 1200 - 2100
M2WH44K9S2LEM Specular Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EM LiFeP04 119 2158 26.5 1200 - 2100
M2WH44K9S2LEP Specular Reflector,Black Bezel 4000K, Ra90 Fixed Output 3 hr EP LiFeP04 119 2158 26.5 1200 - 2100
M2MY23K9S2LEM Specular Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 779.24 8.4 600 - 1100
M2MY23K9S2LEP Specular Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 779.24 8.4 600 - 1100
M2MY33K9S2LEM Specular Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 1536.92 16.6 1200 - 2100
M2MY33K9S2LEP Specular Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 1536.92 16.6 1200 - 2100
M2MY43K9S2LEM Specular Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 2400.09 26.5 2200 - 3100
M2MY43K9S2LEP Specular Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 2400.09 26.5 2200 - 3100
M2WY23K9S2LEM Specular Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 674.52 8.4 600 - 1100
M2WY23K9S2LEP Specular Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 674.52 8.4 600 - 1100
M2WY33K9S2LEM Specular Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 1321.32 16.6 1200 - 2100
M2WY33K9S2LEP Specular Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 1321.32 16.6 1200 - 2100
M2WY43K9S2LEM Specular Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EM LiFeP04 119 2002 26.5 1200 - 2100
M2WY43K9S2LEP Specular Reflector,Black Bezel 3000K, RA90 DALI LED Driver 3 hr EP LiFeP04 119 2002 26.5 1200 - 2100
M2MH23K9S2LEM Specular Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 779.24 8.4 600 - 1100
M2MH23K9S2LEP Specular Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 779.24 8.4 600 - 1100
M2MH33K9S2LEM Specular Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 1536.92 16.6 1200 - 2100
M2MH33K9S2LEP Specular Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 1536.92 16.6 1200 - 2100
M2MH43K9S2LEM Specular Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 2400.09 26.5 2200 - 3100
M2MH43K9S2LEP Specular Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 2400.09 26.5 2200 - 3100
M2WH23K9S2LEM Specular Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 674.52 8.4 600 - 1100
M2WH23K9S2LEP Specular Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 674.52 8.4 600 - 1100
M2WH33K9S2LEM Specular Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 1321.32 16.6 1200 - 2100
M2WH33K9S2LEP Specular Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 1321.32 16.6 1200 - 2100
M2WH43K9S2LEM Specular Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EM LiFeP04 119 2002 26.5 1200 - 2100
M2WH43K9S2LEP Specular Reflector,Black Bezel 3000K, RA90 Fixed Output 3 hr EP LiFeP04 119 2002 26.5 1200 - 2100
Dimensions Diagram 1
VERSION Ø H KG KG(EM) CAØ Cut Aperture
C110 119 100 1.0 1.5 110

Photometric Performance

Photometric Performance Diagram - C110 Medium Specular
C110 Medium Specular
LOR = 100%
Photometric Performance Diagram - C110 Wide Semi-specular
C110 Wide Semi-specular
LOR = 100%
Photometric Performance Diagram - C110 Medium White
C110 Medium White
LOR = 100%
Photometric Performance Diagram - C110 Wide White
C110 Wide White
LOR = 100%
Photometric Performance Diagram - C110 Medium Black
C110 Medium Black
LOR = 100%
Photometric Performance Diagram - C110 Wide Black
C110 Wide Black
LOR = 100%
Photometric Performance Diagram - C110 Medium Specular
C110 Medium Specular
LOR = 100%
Photometric Performance Diagram - C110 Wide Specular
C110 Wide Specular
LOR = 100%

Recessed downlighter with a common appearance across the product family. Narrow 11mm width bezel and shallow depth body. Graphite heat sink for optimum thermal management and superior optics designed for maximum visual comfort. Simple spring ceiling retention method to suit ceiling thicknesses between 1-50mm. Supplied with connected remote driver. Medium round version, 110mm diameter cut out, 118mm over bezel - as Whitecroft MIRAGE 3

Product Downloads

Single download

Add to ZIP

Back to top
